Home | Toggle Clamps | Manual Toggle Clamps | Vertical Toggle Clamps | Front Mounted Fixed Spindle

Front Mounted Fixed Spindle

  • Range:Toggle Clamps
  • Category:Manual Toggle Clamps
  • Group:Vertical Toggle Clamps
  • Style:Front Mounted Fixed Spindle
Search on complete or part product code
Select product to view cad download options
Front Mounted Fixed Spindle
Front Mounted Fixed Spindle
DrawingsPDF
Part No. A B C D E F G I Holding Force Weight
V100/3C 65 122 24.5 7.5 14 17.5 15 4.8 M5 100daN 0.11Kg CAD / BUY
V200/3C 77 170 27 8 19 26 29 5.5 M6x50 200daN 0.25Kg CAD / BUY
V300/3C 114 235 58 19 35 35 30 6.8 M6x60 300daN 0.50Kg CAD / BUY
