Home | Standard Parts | Locking Pins, Index Plungers | Form H | Form H

Form H

  • Range:Standard Parts
  • Category:Locking Pins, Index Plungers
  • Group:Form H
  • Style:Form H
Search on complete or part product code

With Locking Nut
Form H
Form H
DrawingsPDF
Part No. D D1 D2 L L1 L2 H SW F1 F2
45105H 5 M10x1 21 50 24 21 5 17 5 12 Show Options
45206H 6 M12x1.5 25 59 28 25 6 19 6 14 Show Options
45308H 8 M16x1.5 33 77 36 33 8 24 15 35 Show Options
45410H 10 M20x1.5 33 83 40 33 10 30 20 40 Show Options
